Product Overview
Introducing Quick Release Vertical Toggle Clamp by POWERTEC.
This clamp is an absolute must for any jig assembly, tool fixture or movable base. It features a vertical front mount push toggle design that provides an adjustable and secure hold, plus a quick release for many of your woodworking projects that require specific production clamping for drilling, welding or milling.
- INCLUDES: (1) Vertical Handle Toggle Clamp 12050
- FUNCTION: An essential woodworking hand tool addition to your jig assembly, delivering dependable and secure vertical hold down clamp action for your work pieces, jigs and fixtures, also works with 71416 Toggle Clamp Mounting Plate & POWERTEC Universal T Track for woodworking projects (Note: for t-tracks that accept 1/4” hex head bolts and 5/16" t-bolts)
- DESIGN: This heavy duty vertical toggle clamp is constructed from cold-rolled carbon steel, possessing a low profile design, a flanged base, and colored vinyl grip for easy identification
- HOLDING CAPACITY: Vertical clamp can hold up to 200 lbs
- CLAMP SPECS: 1” x 1-1/2” | Mounting holes: 3/16” spaced apart 1/2” x 1-1/16” | Bolt length, including rubber foot: 1-7/8”
Key Features
- A rock-solid grip to install on jigs, tool fixtures, or movable bases
- Cold-rolled carbon Steel with Zinc plated coating for corrosion resistance
- 200 lbs holding capacity ideal for smaller woodworking projects; Complete with adjustable rubber pressure tips
- A minimum 90-degree angle for easy loading and unloading
- Works with 71416 Toggle Clamp Mounting Plate & POWERTEC Universal T Track for woodworking projects (PLEASE NOTE: for t-tracks that accept 1/4” hex head bolts and 5/16" t-bolts)
Common Applications
- Tool Fixtures
- Table Saw Fence
- Table Saw
- Jointing Sled Jig
- Taper Jig
- Wood Working Jigs
Specifications
Clamp base: 1" x 1-1/2"
Mounting holes: 3/16" spaced 1/2" x 1-1/16" apart
Clamp reach from front of clamp base: 1"
Bolt length, including rubber foot: 1-7/8"
Clamp foot adjustable range from bottom of clamp arm: 3/4" - 1-1/4"
Clamp height, including handle, when clamped: 4-1/2"
Total length when clamped: 2-1/2"
